Black Panther X
The Specs
What it is.
What it does.
Hardware. Performance. Motion. All the data you need to know before you build.
Physical Hardware
Dimensions (Standing)
646×368×475 mm
Weight
14.7 kg
Power & Charging
Operating Voltage
26~33.6 V
Charging Method
Standard charger
Battery Life
1.5 hours (no load)
Locomotion Performance
Movement Speed
0~4 m/s
Effective Payload
8 kg
Stair Climbing Height
18 cm
Climbing Ability
30°
Joint & Motion System
Number of Joints
12
Peak Joint Speed
22 rad/s
Peak Joint Torque
33 Nm
Swing Joint
-87°~53°
Hip Joint
-149°~45°
Knee Joint
21°~147°
Built to Perform,
Piece by Piece
Design and Structure
Build. Modify. Upgrade.
Fully modular, 12 high‑performance joints. Clicks like LEGO — performs like real industrial hardware.
Assembled by You
Assembled by You
Build a real industrial-grade robot—piece by piece.
Unlock boundless creativity
0.0 h
0.0 h
8 kg
8 kg
0 DOF
0 DOF
0 cm
0 cm
0°
0°
0 m/s
0 m/s
Command with Ease, Connect with Geeks
Peak Performance at Your Fingertips. Master everything from sprints to backflips through a sleek, intuitive interface.
Join the Evolution.
Access custom move-sets from the community to unlock new skills in seconds.
The last robot dog you will ever need
Community Hub
Built together. Shared openly.
Access 3D files, motion solutions, and mod tips — all shared by users, for users.
Post‑Purchase Coverage
All components needed to build your robotic dog
7-Day Worry-Free Replacement
Full replacement within 7 days for non-human quality issues
Official Tech Community
Access modification guides, firmware updates & tuning tips via App
12-Month Core Warranty
Main control board & battery covered (6 months if modified)
Remote Support
Online customer service for technical troubleshooting
Paid Repairs Available
For wear parts, cosmetic damage, or unauthorized modifications
Full Spare Parts Store
All components available for purchase
Global Partner Distribution Map
We will offer strong technical support and excellent customer resources, and grow together with our partners!
